Carbon steel galvanized steel pipe

Basic Info

Standard: Gb, Jis

Section Shape: Round

Place Of Origin: China

Certification: Bsi

Surface Treatment: Galvanized

Category: Spiral Welded Pipe, Seamless Steel Pipe

Processing Service: Welding

Additional Info

Packaging: Steel Strips bundled, Plastic Caps plugged, Waterproof Paper wrapped etc

Transportation: Ocean

Supply Ability: Delivery Time: Within 30 days and Depends on your order quantity

Port: guangzhounansha

Product Description

Description

Specification

Standard

Painting & Coating

Packing & Loading

Galvanized seamless pipe is divided into cold-plated steel seamless pipe and hot dip seamless pipe.

Hot dip seamless pipe

The Redu seamless pipe is to make the molten metal and iron substrate reaction, the alloy layer, so that the substrate and coating combination of both. Hot-dip galvanizing is the first steel pickling, in order to remove the steel pipe surface of iron oxide, pickling, aqueous solution of ammonium chloride or zinc chloride or ammonium chloride and zinc chloride mixed aqueous solution tank cleaning, and then send into the hot dip tank. Hot dip galvanized coating uniformity, strong adhesion, and long life.

Cold-plated seamless pipe

Cold galvanized, electro-galvanized, galvanized the amount of small, only 10-50g/m2 of its own resistance to corrosion than hot dip galvanized pipe a lot of difference. Regular galvanized pipe manufacturers, in order to ensure the quality, most do not use electro-galvanized (cold-plated). Only those small-scale, outdated equipment and small businesses with electric galvanized, of course, their prices are relatively cheap. The Ministry of Construction has formally below, cold galvanized pipe to eliminate backward technology, the future not be allowed to cold galvanized pipe for water, gas pipes.

Galvanized seamless mechanical properties

The mechanical properties of steel is to ensure that an important indicator of the steel end-use properties (mechanical properties), it depends on the chemical composition and heat treatment of steel. Steel standards, according to different requirements, the provisions of the tensile properties (tensile strength, yield strength or yield point elongation) and hardness, toughness, user requirements, high and low temperature performance.

Application:

1.Building and structural material

2.Mechanical and general engineering purposes

3.Manufacturing of Bus Body, Railway Boogies

4.In Telephone department as Conduit Pipes

Material Inspection (Steel Pipe) — Hanging — De-greasing — Rinsing — Pickling — Washing — Dipping Fluxing — Hot Air Drying — Inside and Outside Hot-dipped Galvanizing Blow— Cooling — Passivation and Rising — Unloading — Inspection and Trimming — Type Identification — Packaging and Storing and Transportation

Types: Galvanzied Welded Steel Pipe, galvanzied Seamless Steel Pipe
Materials: Carbon steel
Connection type: threaded
Size range:1/8″-36″
Schedule: sch40, sch80, sch120, sch160, XH, XXH

Length of the galvanized tubes
- in diameter 4 – 16 mm 6000 + 100 mm
- in diameter 18 – 42 mm 6000 + 50 mm

Tolerances of the zinc coated tubes
- tolerances of the outside diameter:
- diameter between 4 – 30 mm ±0,08 mm
- diameter between 35 – 38 mm ±0,15 mm
- diameter up to 42 mm ±0,20 mm
- tolerances of the inside diameter are according to EN 10305-4
- tolerance of the wall thickness ± 10%

The Steel grades for the zinc coated tubes
E 235+N and E 355+N

Surface condition of the galvanized tubes
First layer – electrolitically leached zinc (Zn) – acts as anode and in a corrosive environment it corrodes first and the base metal is cathodically protected against corrosion. The zinc layer thickness may be in the range of 5 to 30 micrometers (µm).
