Stainless steel plate S

Grade C (%) is (%) manganese (%) P (%) S (%) chromium (%) nickel (%) N (%) and (%) 310 ≤ 0.25 ≤ 1.0 ≤ 2.0 ≤ 0.03--24.0--26.0 19.0--22.0-----
310 seconds ≤ 0.08 ≤ 1.0 ≤ 2.0 ≤ 0.03 ≤ 0.03 24.0-26.0 19.0-22.0------
Differences in mechanical properties of 310/310S stainless steel
Grade tensile strength Mpa yield strength Mpa elongation (%) area reduction rate (%) density (g/cm3)
310 ≥ 470 ≥ 17 ≥ 40 ≥ 50 7.98 310 seconds ≥ 520 ≥ 205 ≥ 40 ≥ 50 7.98

304/304L/304H stainless steel plate

Approximately 304L material: 304L steel is generally low C, and its corrosion resistance is similar to 304, but after welding or stress, it has excellent corrosion resistance to grain boundaries. It can still maintain good corrosion resistance without heat treatment, and is generally used below 400 degrees Celsius (non-magnetic, temperature -196 degrees Celsius to 800 degrees Celsius). Widely used in the production of equipment and parts that require good overall performance (corrosion resistance and formability).
Regarding 304H material: 304H is a type of stainless steel with excellent bending and welding performance, corrosion resistance, high durability, and structural stability, as well as excellent cold deformation ability. The maximum temperature can reach 650 ° C, and the antioxidant capacity can reach 850 ° C
Differences in chemical composition of 304, 304L, and 304H
Grade C (%) Yes (%) Minutes (%) P (%) S (%) Chromium (%) Nickel (%) N (%) 304 ≤ 0.08 ≤ 0.75 ≤ 2.0 ≤ 0.045 ≤ 0.03 18.0-20.0 8.0-10.5 ≤ 0.1 304 liters ≤ 0.03 ≤ 0.75 ≤ 2.0 ≤ 0.045 ≤ 0.03 18.0-20.0 8.0-12.0 ≤ 0.1 304 hours 0.04-1.0 ≤ 0.75 ≤ 2.0 ≤ 0.045 ≤ 0.03 18.0-20.0 8.0-10.5----
Differences in mechanical properties 304 304L 304H
Grade tensile strength (Mpa) yield strength (Mpa) elongation (%) hardness (HR)
304 ≥ 515 ≥ 205 ≥ 40 ≥ 92 304 liters ≥ 485 ≥ 170 ≥ 40 ≥ 92 304 hours ≥ 515 ≥ 205 ≥ 40 ≥ 92
316/316L stainless steel plate
About 316 material: 316 stainless steel greatly improves corrosion resistance and high-temperature strength by adding molybdenum element, with a high temperature of up to 1200-1300 degrees Celsius, and can be used under harsh conditions. The corrosion resistance is better than 304 stainless steel, and it has good corrosion resistance in the pulp and paper production process. 316 stainless steel can also resist erosion from the ocean and corrosive industrial atmosphere.
Approximately 316L material: 316L stainless steel has a carbon content less than 316 and is commonly used in pulp and paper equipment, heat exchangers, dyeing equipment, film washing equipment, pipelines, coastal building materials, etc. The corrosion resistance is better than 316 material.
Differences in chemical composition of 316 316L stainless steel
Grade C (%) Yes (%) Summary (%) P (%) S (%) Chromium (%) Nickel (%) Following (%) Following (%) 316 ≤ 0.08 ≤ 1.0 ≤ 2.0 ≤ 0.045 ≤ 0.03 16.0-18.00 10.0-14.0 2.0-3.0
316 liters ≤ 0.03 ≤ 1.0 ≤ 2.0 ≤ 0.045 ≤ 0.03 16.0-18.0 10.0-14.0 2.0-3.0
Differences in mechanical properties of 316 316L stainless steel
Grade tensile strength Mpa yield strength Mpa elongation (%) area reduction rate (%) density (g/cm3)
316 ≥ 520 ≥ 205 ≥ 40 ≥ 60 7.98 316 liters ≥ 480 ≥ 177 ≥ 40 ≥ 60 7.98
430 stainless steel plate
430 stainless steel is a type of ordinary steel with good corrosion resistance, better thermal performance than austenite, lower coefficient of thermal expansion than austenite, thermal fatigue, addition of Titanium stabilizing elements, and good mechanical properties of welded parts.
430 stainless steel used in architectural use, fuel burner parts, household appliances, home appliance parts
Chemical composition for 430 stainless steel
Grade C (%) Mn (%) Si (%) P (%) S (%) Cr (%) Ni (%) Mo (%) Cu (%) 430 ≤ 0.12 ≤ 1.0 ≤ 0.75 ≤ 0.04 ≤ 0.03 16.0-18.0 ≤ 0.06-- Mechanical property for 430 stainless steel
Grade tension strength Mpa Yield Strength Mpa Elongation (%) rate of reduction in area (%) Density (g/cm3) 430 ≥ 450 ≥ 205 ≥ 22--7.75
Previous: Reduce Next: Push Joint Grade Finish Thickness (mm) Width (mm) Length (mm) 310 2B/No.4/HL/BA/Mirror etc. 0.4mm-0.3mm Standard width in China: 1000mm 1219mm 1500mm
310s No.1 3.0mm-80.0mm Standard width in China: 1219mm 1500mm 2000mm
304 2B, No. 4 PE 0.55 914, 1219 1828, 2438 304 2B, No. 4 PE 0.70 914, 1219 1828, 2438 304 2B, 2B PE, No. 4 PE, BA PE 0.90 914, 1219 1828, 2438 304 2B, 2B PE, No. 4 PE, BA PE 1.20 914, 1219, 1500 1828, 2438, 3000, 3048, 3658 304 2B, 2B PE, No. 4 PE 1.50 914, 1219, 1500 1828, 2438, 3000, 3048, 3658 304 2B, 2B PE, No. 4 PE 1.60 914, 1219, 1500 1828, 2438, 3000, 3048, 3658 304 2B, 2B PE, No. 4 PE 2.00 914, 1219, 1500 1828, 2438, 3000, 3048, 3658 304 2B, 2B PE, No. 4 PE 2.50 914, 1219, 1500 1828, 2438, 3000, 3048, 3658 304 2B, 2B PE, No. 4 PE 3.00 914, 1219, 1500 1828, 2438, 3000, 3048, 3658 304L 2B, 2B PE 4.00 1500, 2000 3000, 6000 304H 2B/No. 4/HL/BA/Mirror etcNo.1 3.00 1219, 15002000
310 2B/No.4/HL/BA/0.4-0.3 100012191500
310s No.1 3.00 1219, 15002000
316 2B 0.55 1219 2438 316 2B 0.70 1219 2438 316 2B 0.90 1219 2438 316 2B, No. 4 PE 1.20 1219 2438 316 2B, No. 4 PE 1.50 1219, 1500 2438, 3000, 3658 316 2B, No. 4 PE 1.60 1219, 1500 2438, 3000, 3658 316 2B, No. 4 PE 2.00 1219, 1500 2438, 3000, 3658 316 2B, No. 4 PE 2.50 1219, 1500 2438, 3000, 3658 316 2B, No. 4 PE 3.00 1219, 1500 2438, 3000, 3658 316 2B, No. 4 PE 3.00 1219 38, 3000, 3658 316L 2B, 2B PE 4.00 1500, 2000 3000, 6000 430 BA PE, No. 4 PE 0.70 914, 1219 1828, 2438 430 BA PE, No. 4 PE 0.90 914, 1219 1828, 2438 3CR12 2B 1.2 1250 2500 3CR12 2B 1.6 1250 2500 3CR12 2B 2.0 1250 2500 3CR12 No 1 4.0 1250, 1500 2500, 3000, 6000 Other grades and widths
Grades: 301L, 310, 321, 2205, 253MA
Widths (mm): 600, 750, 900, 1050, 1200, 1524
310/310S stainless steel sheet
Grade GB/T 1220-2007 ASTM DIN JIS KS 310 20Cr25Ni20 310 1.4821 SUS310 STS310 310S 06Cr25Ni20 310S 1.4845 SUS310S STS310S
Standards for 304 304L 304H stainless steel
Grade GB/T 1220-2007 ASTM DIN JIS KS 304 06Cr19Ni10 304 1.4301 SUS304 STS304 304L 022Cr19Ni10 304L 1.4306 SUS304L STS304L 304H -304H - SUS304H
Standards for 316/316L stainless steel
Grade GB/T 1220-2007 ASTM DIN JIS KS 316 06Cr17Ni12Mo2 316 1.4401 SUS316 STS316 316L 022Cr17Ni12Mo 316L 1.4404 SUS316L STS316L Standards for 430 stainless steel
Grade GB ASTM DIN JIS 316 10Cr17 430 1.4016 SUS430
Thickness Austenitic nominal mass (kg/m ²) Ferritic nominal mass (kg/m ²)  0.45 3.68
0.55 4.50
0.70 5.72
0.90 7.36
1.20 9.81 9.61 1.50 12.3
1.60 13.08 12.85 2.00 16.35 16.02 2.50 20.44 20.03 3.00 24.53 24.04 4.00 32.71 32.06
Grade of stainless steel plate
Surface smoothness of stainless steel plate
Surface smoothness
definition
application
2B
After cold rolling, heat treatment, pickling or other equivalent treatments, the final product is obtained with appropriate gloss through cold rolling.
Medical equipment, food industry, building materials, kitchen utensils.
eight
The ones that undergo bright heat treatment after cold rolling.
Kitchen utensils, electrical equipment, and building construction.
NO.3 (in English)
Polish the abrasive with the 120 to 6001 abrasive specified in JIS R100.
Kitchen utensils, building construction.
NO.4
Polish the abrasive with grit 180 to 6001 as specified in JIS R150.
Kitchen utensils, building construction, medical equipment.
HL type
The completed polishing is done in order to generate continuous polishing stripes by using appropriate grit abrasives.
Construction.
NO.1
The corresponding process of heat treatment, acid washing or hot rolling on the surface.
Chemical tanks and pipelines.
No.8 (in English)
High reflective "mirror" decoration Alloy Steel Pipe
