best quality astm a632 stainless steel pipe

Basic Info

Standard: Astm, Jis, Din

Section Shape: Round

Place Of Origin: China

Application: Fluid Pipe, Hydraulic Pipe, Gas Pipe, Oil Pipe, Structure Pipe

Surface Treatment: Galvanized

Category: Welded Steel Pipe, Seamless Steel Pipe

Processing Service: Welding

Additional Info

Packaging: Bundles with waterproof cloth outside.or plywood box. or for the client's requirement

Transportation: Ocean

Place of Origin: Foshan City, Guangdong Province

Supply Ability: Within 30 days and Depends on your order quantity

Port: gaungzhounansha

Product Description

This specification covers the grades of stainless steel pipes used for general corrosion resistance and low or high temperature services. The pipes should be cold processed and made using seamless or welding processes. All materials should be provided under heat treatment conditions. The heat treatment procedure should include heating the material and quenching it in water or rapidly cooling it by other means. The tensile test, expansion test, water pressure test, underwater pressure test, and non-destructive electrical test should be carried out in accordance with the specified requirements.

This specification covers Stainless Steel Pipe grades with dimensions less than 1/2 to 0.050 inches. (12.7 to 1.27 millimeters), with an outer diameter and wall thickness less than 0.065 inches. As low as 0.005 inches (1.65 to 0.13 mm) for general corrosion resistance and low or high temperature conditions, as shown in Table 1.
Note 1: According to this specification, the austenitic stainless steel pipe grades provided have been found to be suitable for low temperature conditions as low as -325 ° F (-200 ° C), where the impact value of the simply supported beam notch rod is 15 ft · lbf (20 J), the minimum value, and these grades do not require impact testing.
(A) A new name established based on Practice E527 and SAE J 1086 Practice of Metals and Alloys (UNS).
(B) For seamless TP316L pipes, the maximum silicon value should be 1.00%.
(C) For welded TP 316 pipes, the nickel range should be 10.0-14.0%.
(D) The Titanium content of TP 321 grade should not be less than five times the carbon content and not exceed 0.60%.
(E) The niobium and tantalum content of TP 347 and TP 348 grades should not be less than ten times the carbon content and not exceed 1.0%.
1.2 provides optional supplementary requirements, which should be stated in the order if necessary.
1.3 Values in inches pounds should be considered standard values. The values given in parentheses are mathematical conversions of SI units and are for reference only and not considered standard.
Annealed and acid washed surfaces, bright annealed surfaces, outer diameter polished surfaces, outer diameter and inner diameter polished surfaces, etc.
Surface smoothness
definition
application
2B This is finished, after cold rolling, by heat treatment, picking or other equivalent treatment, and last by cold rolling to give appropriate wine
Medical equipment, Food industry, Construction material, Kitchen utensils
BA That processed with bright heat treatment after cold rolling
Kitchen utensils, Electric equipment, Building construction
NO.3 This finished by polishing with No.100 to No.120 abrasives specified in JIS R6001
Kitchen utensils, Building construction
NO.4 This finished by polishing with No.150 to No.180 abrasives specified in JIS R6001
Kitchen utensils, Building construction, Medical equipment
HL That finished polishing so as to give continuous polishing streams by using aggressive of suitable grain size
Building construction NO.1 The surface finished by heat treatment and picking or processes responding there to after hot rolling
Chemical tank, pipe
